How to remove Jeep Wrangler Hard Top removal


How to Remove Jeep Wrangler Hard Top: Step-by-Step Guide

To remove the Jeep Wrangler hard top, you have to go in order using this step-by-step guide. As Jeep owners know, it takes a few times to get the hang of removing the hard top. Once you get the hang of it, you will get the Jeep Wrangler top off hassle-free. Follow the steps below on how to remove Jeep Wrangler hard top and contact Napleton's Northlake Jeep dealer if you have any more questions.

Steps on How to Remove Jeep Wrangler Hard Top: Front 2 Panels

  1. Open both the front doors and put the sun visors down to the point it touches the windshield
  2. Turn the L-shaped locks to unlock: 4 located on the front and rear center on the roof panel and 2 on the outboard side of the panel, above the shoulder belt
  3. Unlatch the header panel latch: located at the top of the windshield, above the sunshade
  4. Remove one panel at a time (driver side first) by pushing up: carefully remove it so it doesn't scratch
  5. Store the 2 panels in the storage bag that comes with your Jeep Wrangler and place them in the trunk or somewhere secure
Now that the two front panels are removed, you can finish taking the rest of the Jeep Wrangler top off. Follow the back piece Jeep Wrangler hard top removal steps:

Next Steps to Jeep Wrangler Hard Top Removal: Back Piece

  1. Open the trunk (swing gate) all the way and lift the rear window glass
  2. Take the #50 Torx head driver and ratchet, and remove the Torx head screw at the B-pillar near the top of each front door (this secures the Wrangler hard top in front)
  3. Using the same tool, remove the 6 (3 on each side) Torx head screws found inside the vehicle (these secure the Jeep Wrangler hard top to the vehicle)
  4. Once the screws are removed, on the left-rear inside corner you'll see the wiring harness. Disconnect the harness from the hard top by pushing the lock tab down then pushing upward and pulling down to disconnect
  5. You'll see the washer hose next to it, disconnect that by pushing the release button on the connecter and pulling down
  6. With the help of others, remove the Jeep Wrangler hard top. Carefully lift it up and carry it off. Place it on a soft surface and somewhere dry

Jeep Hard Top Removal: Things to know

  • The hard top consists of a Three-Piece Modular Freedom Top: 2 front panels and 1 large back piece
  • Need the #50 Torx head driver and ratchet to remove screws (this comes with your Jeep Wrangler)
  • Lift the compartment cover in the trunk and store your screws in its holder
  • The help of at least one other person or more is recommended
  • Secure Jeep Wrangler hard top in a safe, dry, soft place to minimize damage
  • Keep the rear window glass up when the hard top is off, this helps prevent damage to the window



How to remove Jeep Wrangler hard top

Enjoy your Jeep Wrangler Top Off

Enjoy the fresh air when driving around in your Jeep Wrangler with the top off. When you are ready to put your Jeep Wrangler hard top back on, just follow the same steps but in reverse order. Removing the Jeep Wrangler hard top gets easier every time you do it. Follow the steps and you will get your Jeep Wrangler top off easily. If you have any questions on the Jeep Wrangler hard top removal, contact Napleton's Northlake Jeep. We look forward to helping you enjoy your Jeep Wrangler with the top off!



Removing Jeep Wrangler Hard Top FAQ

How to remove Jeep Wrangler hard top?

  1. Turn all L-shaped locks to unlock on the two front panels and unlatch the header panel latch
  2. Once unlocked, remove each panel one at a time starting with drivers side
  3. Once panels are removed, open swing gate and lift rear window glass
  4. Take the #50 Torx head driver and ratchet, unscrew head screw at the B-pillar on each side
  5. Using the same tool, unscrew the 6 Torx screws (3 on each side) inside the vehicle that secures the top to the vehicle
  6. Located on the left-rear inside corner, disconnect the wiring harness by releasing the locking tab, pushing inward and pulling down to disconnect
  7. Disconnect the washer hose next to it by pushing the release button and pulling down
  8. Once all screws are out and items are disconnected, carefully (with the help of others) lift the Jeep Wrangler hard top piece up and place it down on a soft, dry, safe spot

Are Jeep Wrangler hard top removable?

Yes, Jeep Wrangler hard tops are removable, follow our step-by-step guide on how to remove Jeep Wrangler hard top.
